PR02-40x51-R_23x80F-HP-R-70-L_MS11_TS00
Linear Rotary Motor, Hollow shaft, MagSpring 11N
PR02-40x51-R_23x80F-HP-R-70-L_MS11_TS00
PR02-40x51-R_23x80F-HP-R-70-L_MS11_TS00

PR02-40x51-R_23x80F-HP-R-70-L_MS11_TS00

Linear Rotary Motor, Hollow shaft, MagSpring 11N
Item No. 0150-7036
Status

Active

Standard delivery programm

6 - 8 Weeks
Balancing
Gripper
Force Sensor
Hollowshaft
MagSpring

‌
Technical data linear part
Max. Stroke 70 mm (2.76 in)
Max. Force 67.1 N
Continuous Force 24.4 N
Max. Velocity 7.30 m/s
Repeatability 0.05 mm (0.002 in)
Load Compensation 11 N
‌
Technical data rotary part
Max. Torque 1.2 Nm
Continuous Torque 0.25 Nm
Max. Number of Revolutions 1500 rpm
Repeatability Rotary Motor 0.100 °
‌
Mechanical data
Length 341 mm (13.43 in)
Mass 2630 g (5.8 lb)
Diameter Linear Part 40 mm (1.57 in)
Diameter Rotary Part 96 mm (3.78 in)
Moving Mass (Linear) 517 g (1.14 lb)
Axle Diameter 10h9
Protection Class IP64
