PR02-52x60-R_37x120F-HP-R-100_MS01_TS00_SSCH
Linear Rotary Motor, Stainless steel housing, MagSpring 30N

PR02-52x60-R_37x120F-HP-R-100_MS01_TS00_SSCH

Linear Rotary Motor, Stainless steel housing, MagSpring 30N
Item No. 0150-6180
Status

Active

Standard delivery programm

3 - 5 Weeks
Balancing
Gripper
Force Sensor

‌
Technical data linear part
Max. Stroke 100 mm (3.94 in)
Max. Force 255.0 N
Continuous Force 51 N
Max. Velocity 3.90 m/s
Repeatability 0.05 mm (0.002 in)
‌
Technical data rotary part
Max. Torque 2.2 Nm
Continuous Torque 0.47 Nm
Max. Number of Revolutions 1500 rpm
Repeatability Rotary Motor 0.100 °
‌
Mechanical data
Length 441 mm (17.36 in)
Diameter Linear Part 58 mm (2.28 in)
Mass 8400 g (18.52 lb)
Diameter Rotary Part 138 mm (5.43 in)
Moving Mass (Linear) 1075 g (2.37 lb)
Axle Diameter 12h9
Protection Class IP69S

The item has been added to your shopping cart.
The item has been added to your shopping cart.
The item has been added to the watch list.
The item has been added to the watch list.

This article ist not available. Yo can get a message when this article will be available again. Please fill in your mail adress and click on "send".

Details

‌
Technical data linear part
Max. Stroke 100 mm (3.94 in)
Max. Force 255.0 N
Continuous Force 51 N
Max. Velocity 3.90 m/s
Repeatability 0.05 mm (0.002 in)
‌
Technical data rotary part
Max. Torque 2.2 Nm
Continuous Torque 0.47 Nm
Max. Number of Revolutions 1500 rpm
Repeatability Rotary Motor 0.100 °
‌
Mechanical data
Length 441 mm (17.36 in)
Diameter Linear Part 58 mm (2.28 in)
Mass 8400 g (18.52 lb)
Diameter Rotary Part 138 mm (5.43 in)
Moving Mass (Linear) 1075 g (2.37 lb)
Axle Diameter 12h9
Protection Class IP69S

Documents

Name Version Typ Größe
Data sheet 0185-0227 (EN): Linear Rotary Motors PR02-52 SSCH 1V0 PDF 579.87K
Data sheet 0185-0227 (EN): Linear Rotary Motors PR02-52 SSCH 1V0 PDF 577.29K
Installation guide 0185-0228 (DE): Linear rotary motors PR02-52 SSCH 1V0 PDF 1.78M
Installation guide 0185-0228 (EN): Linear rotary motors PR02-52 SSCH 1V0 PDF 1.86M

CAD

Name Version Typ Größe
CAD drawing 0186-2008: PR02-52x60-R_37x120F-HP-R-100_MSxx_TS00_SSCH 241120 STEP 2.40M

Software

Name Version Typ Größe
User manual 0185-1098 (EN): Tutorial LinMot Designer 1V102 PDF 4.14M
EPlan Macros 1V0010 ZIP 19.66M
LinMot Designer Motor Sizing Software (PC) 1V11 PDF 3.79M
LinMot Designer Motor Sizing Software (PC) 1V11 EXE 8.82M
LinMot Designer Motor Sizing Software (PC) 1V11 ZIP 8.24M
